- 70 mm ID x 150 mm OD x 35 mm Wide
- Open
- ABEC 1
- Standard Cage
- Normal Clearance
description
- Angular contact ball bearings have raceways in the inner and outer rings, which are displaced with respect to each other in the direction of the bearing axis. Designed to accommodate both radial and axial loads (in one direction).
applications
- Pumps
- Compressors
- Centrifuges
features
- Inner and outer ring raceway
- Suitable for simultaneously acting radial and axial loads
- Axial load capacity increases with increasing contact angle
compliances
- 0
| I.D. | 2.76 in, 70 mm |
| icNumber | 7695809 |
| O.D. Type | Cylindrical |
| Seal Material | None |
| Outer Ring Width | 1.38 in, 35 mm |
| Precision Level | Standard (ABEC 1) |
| Locating | Retaining Slot |
| Cage Material | Brass |
| Series | 7300 |
| No. in Set | Single Bearing |
| Bearing Design | Universal Mounting |
| Snap Ring | No Snap Ring |
| Precision | Standard |
| Seal Type | Unsealed |
| Ball Material | Steel |
| Bearing Type | Unmounted, Angular Contact |
| Lubricant | Oil Preservative |
| Flush Ground | No |
| Contact Angle | 40 Degree |
| Cage Type | Metal |
| Bore Type | Cylindrical |
| Inner Ring Width | 1.38 in, 35 mm |
| Radial Internal Clearance | Normal |
| Capacity | High Capacity |
| Enclosure | Open |
| Radial Internal Clearance Specification | Normal Clearance |
| Limiting Speed - Oil | 5000 rpm |
| Rows of Balls | Single |
| Preload Level | Light |
| Inch/Metric | Metric |
| O.D. | 5.91 in, 150 mm |
| Width | 1.38 in, 35 mm |
| Locking Device | No Locking Device |
| Material | Bearing Steel |
| Limiting Speed - Grease | 3800 rpm |
| Weight | 6.349 LB |
| EAN or UPC | 7316570058048 |
