- 1 hp
- 1,800 rpm
- 208/230/460 Volts
- Three Phase
- 60 Hz
applications
- Food processing
- Packaging
- Outdoor applications
features
- Moisture-resistant insulation system
- Sealed ball bearings with moisture-resistant grease
- Contact lip seals on fan shaft extensions
- Neoprene gaskets
- 300 series stainless steel motor frame, base, shaft and hardware
- No exterior paint
- Non-contact labyrinth seal or output shaft extension
| Service Factor | 1.15 |
| Mult. Sym. | K |
| Product Line | RG |
| Frame Size | 56C |
| Brake Feature | No |
| RefPicture | CSWDM |
| Open End Bearing | 6203 |
| Motor Application | Premium Efficient, Washdown Duty |
| RPM | 1,800 rpm |
| Full Load Pf | 81 |
| Drive End Bearing | 6205 |
| Voltage | 230/460 |
| Enclosure | TENV |
| Poles | 4 |
| Rotation | R |
| Enclosure Designation | TENV - Totally Enclosed Non-Ventilated |
| Type | 3524M |
| Phase | Three Phase |
| Hz | 60 Hz |
| Full Load Efficiency | 85.5 % |
| Design | B |
| Efficiency Group | Premium Efficient |
| VoltCode | E |
| Useable at 208V | Yes |
| Full Load Amps | 1.4 |
| Mounting | C-Face - With Base |
| Mounting Style | F-1 |
| Voltage Rating | 230/460 |
| Full Load rpm | 1740 rpm |
| Washdown Duty | Yes |
| Frame | 56C |
| Weight | 39.0 LB |
| EAN or UPC | 781568490914 |
-
![IP55]()
IP55
